Product details
The speaker cabinet is made of custom European-grade multilayer plywood,
with a surface coated in waterproof diamond sand and treated under high temperature and pressure.
The front of the cabinet features a 2mm thick perforated protective steel mesh,
and is lined with multiple layers of waterproof sound-permeable material, providing strong resistance to wear, water, and moisture.
Product technical specifications
Frequency response：85Hz-19.5KHz（-10dB）
Nominal Directivity HxV（-6 dB)：75°×15°
Nominal Sensitivity ity（1W/1m）：103dB
Maximum Peak SPL：132dB/138dB (Peak)
Power Handing(AES/Peak)：LF：800W（Rated）/3200W（Peak）
HF：110W（Rated）/440W（Peak）
Driver Components：LF：2×10" Driver
HF：1×3" Driver
Nominal lmpedance：8Ω
Input Connection：2x Neutrik NLT4M（+1/-1）
Rigging：4-point connection
Bending Angle：0°-14°，2° Enter
Dimension(mm)：H/W/D（800/388/515）mm
Weight：35KG
Case Material：First grade multi-layer plywood
Surface Treatment：PCP
Protection rating：IP54
