Product details
Product technical specifications
Output power（EIA 1KHz1%THD） | Stereo | 8Ω、2×2000W | Distortion | ≤0.02％ |
4Ω、2×3000W | Separation at rated output power,8OHMS,1kHz | 62dB | ||
2Ω、2×3000W | DF,f=1kHz,8OHMS | >300 | ||
Bridge | 8Ω、N/A | Slew rate | 15V/uS | |
4Ω、N/A | Protect | Soft start、Short-circuit protection、Clipping protection、DC Fault protection、AC Fuse protection、Fusing protection | ||
Input interface | SPEAKON | Cooling system | Dual fans | |
Frequency response | 20Hz-20kHz，-3dB~+0.5dB | Power supply | AC：220V-230V，50Hz/60Hz | |
Input sensitivity | 27dB/28.5dB/29dB/30dB/30.5dB/32.5dB/38dB/41.5dB | Net weight（kg） | 13.5kg | |
Balanced input impedance | 20kΩ/Balanced input，10kΩ/Unbalanced input | Dimensions（W×D×H） | 482×389×88mm | |
SNR | ≥105dB | |||
